Material:
Housing: Thermoplastic, Ul94 V-0, Black
Contact: Copper Alloy
Shell: Stainless Steel
Finish:
Contact: 50u"Min. Nickel Under Plated,
Plated 3u "Au On Contact Area,
Plated Gold Flash On Solder Area.
Electrical Specifications:
Voltage Rating: 12 VAC
Current: 1 Amperes Max. Per Contact
Operation Temperature Range: -25℃ ~ +70℃
Contact Resistance: 60MΩ Max.
Insulation Resistance: 1000MΩ Min
Dielectric Withstanding Voltage: 500V Ac For 1Minute
Max Processing Temp: 260°C For 30 Seconds
Package: Tape Reel Package, 1000pcs/Reel |
