Can output PWM dimming signals. All models have built-in photosensitive sensors.
Zhaga boook-18 stree lighting Controller
Model
KLS20-JL-731A1
KLS20-JL-731A2
Power Supply
Rated voltage：12~24VDC
Rated current：10mA
Power Consumption
12V/5mA；24V/6mA
Sensor Type
Photosensitive tube
Spectral Acquisition Range
350~1100nm，Peak wavelength 550nm
Dimming interface
Type：PWM
Turn on Illuminance
50Lux（±10）
Turn off Illuminance
Reflected light + 40Lux（±10）after each turn on
Lower limit：50+40Lux（±10）
Upper limit：6000Lux（±100）
Reflected light compensation upper limit
6000Lux（±100）
Initialization
After power on, the light is turned on by default and maintains 5S, then automatically turns off the light and enters the auto-sensing operation mode *1
Turn on delay
5s
Turn off delay
20s
0%~100%；100%~0%
Brightness change time
8s
Midnight Dimming
NC
Trigger: the average center point of the first ten days
(The first day default call night base is 10 hours)
Dimming Ratio:50%
Duration Ratio:40%
Less than 10 days is calculated based on the actual number of days
