Electrical Specifications:
| Standards |
GPS&GLONASS&GALILEO&BEIDOU |
| Frequency range (MHz) |
1559-1609MHz |
| Peak Gain (dBi) |
3.4~4.4 |
| Average Gain (dB) |
-2.2~1.5 |
| VSWR |
<1.4 |
| Return Loss |
<-16.5 |
| Efficiency (%) |
59.8-71.6 |
| Polarization mode |
Linear |
| Radiation pattern |
Omni-Directional |
| Output impedance (Ω) |
50 |
| Max. Input Power(W) |
5 |
Note: All parameters are measured with KLS's EVK which size is 80*35mm
Mechanical and Environmental Specification:
| Mounting Type |
SMD |
| Antenna size(mm) |
7.0(L) x5.8 (W) x 0.4(H) |
| Material |
PCB |
| Operating Temperature(℃) |
-40℃ ~ +85℃ |
| Storage Temperature(℃) |
-40℃ ~ +85℃ |
|
