Material: Plug Housing：PBT Socket Housing：PBT Body: High performance engineering plastics UL94-V0/Zinc alloy
Contact: Phosphor bronze,gold plated
Sealing: silica gel
Electrical Characteristics: Insertion loss : 0.7db
Retum loss : 65db
Mechanical life : 500 times min
Humiture Temperature :- 20℃~+85℃;humidity≤85%
Vibration Frequency : 5~200Hz，Amplitude:5mm,speed:10m/s
Salt spray : PH6.5~7.2，NaCI,5% 48H
Waterproof level: IP67
Life: 500 cycles Min.
Operating Temperature: -40ºC~+80ºC
