| Features |
| 1. Charging socket conforms to SAE J1772-2016 standard |
| 2. Concise appearance, support back installation |
| 3. Safety pins insulated head design to prevent accidental direct contact with staff |
| 4. Overall product protection level 3S,Back protection class IP65 |
|
| Mechanical properties |
| 1. Mechanical life : no-load plug in/pull out＞10000 times |
|
| Electrical Performance |
| 1. DC input: 80A/150A/200A 600V DC |
| 2. AC input: 16A/32A/60A 240/415V AC |
| 3. Insulation resistance：＞2000MΩ（DC1000V） |
| 4. Terminal temperature rise：＜50K |
| 5. Withstand Voltage：3000V |
| 6. Contact Resistance： 0.5mΩ Max |
|
| Applied Materials |
| 1. Case Material: Thermoplastic,flame retardant grade UL94 V-0 |
| 2. Pin：Copper alloy,silver + thermoplastic on the top |
|
| Environmental performance |
| 1. Operating temperature: -30°C~+50°C |
|
