M23 waterproof Plastic circular connectors,IP68,Solder type,Quick lock M23 connector is made of copper alloy,pa66 nylon raw material,has corrosion resistance,ensure fast signal transmission and conductive.Double silicone pad combination to achieve ip68 waterproof and dustproof effect.
Order Information: KLS15-EWC03A-M23-2-F1-A
(1) (2)(3) (4)
(1) M23 Shell Size
(2) 2,3,4,5 pins
(3) F1-Plug Socket T1-Docking Plug Pin M1-Flange receptacle M2-Circrlar receptacle
(4) Line diameter range A-5~9mm B-9~12mm
Number of Poles : 2/3/4/5Pin Rated Voltage : 450V Rated Current : 30A(2-3P),15A(4-5P) Wire Section : 5~9mm,9~12mm Mating Cycle : 1500 Mating Cycle Temperature Range : -40℃-+105℃ Wire Section : 0.5-4MM^2(2-3P),0.5-2.5MM^2(4-5P) Housing Material : PA66 Contact/Terminal Materials : Copper Alloy
