M5 circular connector is specially developed for the miniature sensor market and any application that requires multiple sensors
within a very small area. The product line offers 3 and 4 Pins cable cord-sets and a range of panel-mounted receptacles. All
connectors are either factory PVC/PUR over-molded or panel receptacles supplied with single wires or PCB solder pins, which is
very compact and convenient for the application in narrow installment places.
● Cable plugs and panel receptacles are available
● Cable length base on customer requesting
● TPU over molded, IP67 protection degree
● 3, 4 poles per connector are available
● Operating voltage 60V,
● Operating current 1A
Order information:
KLS15-M5 A-TR3-03-PUR-L2.0M-B-W
M5: Screw type
A: Coding
TR3: Plug male pin,Right angled
Number of contacts: 3 pins or 4 pins
Cable jacket: PUR or PVC
Cable length:2.0M,3.0M,4.0M,5.0M...other customized lengthes
Cable colour: B-black
W-With Shielded U-Un shielded
