Mini HDMI Connector With Female Solder 19P
How to order Example:
KLS1-328-1-N-1-R
Series No: 1-Steel Shell
Shell Plate: N=Nickel G=Gold
Terminal Plate: 1=1u" 3=3u" 5=5u" 10=10u" 15=15u" 30=30u"
Material:
Housing: LCP, E130i, UL94V-0, Black
Terminal: C2680R-H
Shell: C2680R-H, T=0.4mm, Ni Plating All Over
Electric:
Rated Voltage: 40V
Rated Current: 0.5AMP
Dielectric Withstanging Viltage: 500V AC/Minute
Insulation Resistance: 100MΩ MIN
Contact Resistance: 30mΩ Max
Insertion Force: 4.5 kgf Max
Withdrawing Force: 1kgf~4kgf
Life: 10000 Cycles
Operating Temperature: -25℃ ~ +85℃
|
