SMD magnetic buzzer,Externally driven type,Top sound KLS3-SMT-05*03 All Products in SMD magnetic buzzers

SMD magnetic buzzer,Externally driven type,Top sound


  Product Images
SMD magnetic buzzer,Externally driven type,Top sound


  Product Information
SMD magnetic buzzer,Externally driven type,Top sound

Oscillation Frequency:            4.0KHz
Rated Voltage:                        3Vo-p
Operating Voltage:                  2~4Vo-p
Rated Current:                        110mA Max.at Rated Voltage
Sound Pressure Level:           75dB Min.at 10 cm at Rated Voltage
Coil Resistance:                      12±3Ω
Operating Temp:                      -40~+105°C
Weight:                                     0.6g

Housing Material:                     LCP

Size:

Picture Part No. PDF Description Order Qty. Time Order
KLS3-SMT-05*03SMD Electromagnetic Buzzer,Size:5*5*3.0mm,80dB @10cm,Operating Voltage:2~4Vo-p,Max.Rated Current:110mA,Rated Voltage:3.0Vo-p,4000Hz.
