Externally driven magnetic buzzers,Top sound
Resonance Frequency : 2.048KHz
Operating Voltage: 1~3 Vo-p
Rated Voltage: 1.5 Vo-p
Current Consumption: 30mA Max.at Rated Voltage
Sound Pressure Level: 85dB Min at Rated Voltage at 10cm
Operating Temp: -40~+85°C
Weight: 1.0g
Housing Material: PPO
Size:
| Order Code |
Operating Voltage |
Resonant Frequency |
Max.Rated Current |
Min.S.P.L.（@10cm） |
Rated Voltage |
| KLS3-MT-12*8.5-A |
1~2V |
2048Hz |
30mA |
85dB |
1.5V |
| KLS3-MT-12*8.5-B |
1~2V |
2048Hz |
10mA |
80dB |
1.5V |
|
