- • Target gas: Carbon Dioxide, CO2
- • Super low power consumption(<0.2mA)
- • Great accuracy(+30ppm&3% reading value)
- • Mini size, easy to integrate
- • Applications:Smart thermostat, portable CO2 detector, air quality monitor, air purifier
- Principle Introduction:
MH-Z1311A carbon dioxide gas sensor (hereinafter referred to as the sensor) is a general-purpose, small-scale sensor that uses the principle of non-dispersive infrared (NDIR) to detect CO2 in the air. It has good selectivity, no oxygen dependence, and long life. , Built-in temperature compensation, digital output, easy to use. The sensor is a high-performance sensor made by closely combining mature infrared absorption gas detection technology with precise optical circuit design and sophisticated circuit design.
   |
