Flange Panel Mount F Connector (Jack Female,75 Ω) KLS1-F004B |
 All Products in F connectors |
|
 |
Flange Panel Mount F Connector With Jack Female Straight Type
Size:
| Connector Style |
F Type |
| Connector Type |
Jack, Female Socket |
| Contact Termination |
Solder |
| Shield Termination |
Solder |
| Impedance |
75 Ohm |
| Mounting Type |
Panel Mount, Square Flange |
| Cable Group |
- |
| Fastening Type |
Threaded |
| Frequency - Max |
2GHz |
| Features |
Extended Insulation |
| Housing Color |
Gold |
| Ingress Protection |
- |
| Body Material |
Brass |
| Body Finish |
Nickel |
| Center Contact Material |
Brass |
| Center Contact Plating |
Tin |
| Dielectric Material |
Polytetrafluoroethylene (PTFE) |
|
