High Dielectric Constant Ceramic Capacitor
SPECIFICATIONS
| Item |
Specification |
| Capacitance |
100pF～22000pF |
| Capacitance Tolerance |
K(±10%),M(±20%),Z(+80%-20%) |
| Operating Temperature |
-25～85℃ |
| Temoerature Characteristic |
Y5P、Y5U、Y5V |
| Rated Voltage |
50～160,250,500VDC |
| Dissipation Factor(tgδ) |
tgδ≤2.5%
@ 1KHz,1±0.2Vrms,25℃ |
| Voltage Proof |
2.5Ur |
| Insulation Resistance(IR) |
IR≥10000MΩ @ 25℃,the rated voltage |
| Testing Voltage |
3 times the rated voltage |
|
|
3.CAPACITANCE CHART
Rated
Voltage |
Dimension |
Temperature Characristic |
Lead Size |
| Y5P（B） |
Y5U（E） |
Y5V（F） |
| Diameter |
Thick |
Nominal
Cap. |
Plate
Size |
Nominal
Cap. |
Plate
Size |
Nominal
Cap. |
Plate
Size |
Space |
Diameter |
| 50～160 |
5.0 |
3.0 |
221～152 |
4718 |
152～502 |
4718 |
222～682 |
4718 |
2.5±0.8 |
0.40±0.05 |
| 5.5 |
182～222 |
5018 |
682 |
5018 |
103 |
5016 |
| 6.5 |
252～332 |
5818 |
822～103 |
6018 |
103 |
6020 |
5.0±1.0 |
0.45±0.05 |
| 7.5 |
472 |
6818 |
|
|
|
|
| 8.0 |
502～562 |
7518 |
|
|
|
|
| 9.0 |
682 |
8520 |
|
|
153～223 |
8220 |
0.53±0.05 |
| 10.5 |
822～103 |
9820 |
|
|
|
|
| 500 |
5.0 |
4.0 |
151～561 |
4835 |
102～222 |
5040 |
|
|
5.0±1.0 |
0.45±0.05 |
| 5.5 |
681～102 |
5035 |
|
|
222～332 |
5040 |
| 6.0 |
122 |
5535 |
|
|
|
|
| 6.5 |
152 |
6035 |
272～392 |
5840 |
392～562 |
6040 |
| 7.0 |
182 |
6535 |
|
|
|
|
| 7.5 |
222 |
7035 |
472～502 |
7040 |
682 |
7040 |
| 8.0 |
272 |
7535 |
682 |
7640 |
|
|
| 8.5 |
|
|
|
|
822～103 |
8040 |
| 9.0 |
332 |
8435 |
|
|
|
|
0.53±0.05 |
| 9.5 |
392 |
8835 |
822～103 |
9035 |
|
|
| 10.5 |
472 |
9835 |
|
|
223 |
9530 |
| 12.5 |
682 |
11535 |
|
|
|
|
| 14.5 |
103 |
13535 |
|
|
|
|
| Capacitance Tolerance |
±10，±20% |
±20% |
80/-20% |
|
|
| Packing Style |
Bulk，Taping |
|
|
|
| |
KLS10-HLK-DC50V-Y5P-102-K
|
